Performance
Max Throughput Up to 1.0 Gbps IP (1.7 Gbps PHY)
Client Capacity 100 Clients (WiFi Interop); 44 Clients (SRS)
Wireless Protocols Wi-Fi Interop
Mimosa GPS Sync (TDMA)
Coverage Radius Recommended < 300 m/1000 ft for optimal performance
Radio
MIMO & Modulation MIMO & Modulation
Bandwidth* 20/40/80 MHz channels
Tunable in 5 MHz increments with GPS Sync
Tunable to standard WiFi channels for WiFi Interop
Frequency Range GPS Sync: 4900-6400*** MHz
WiFi Interop: 5170-5835 MHz

Restricted by country of operation
(*new* US/FCC 5600-5650 support)
Max Output Power 30 dBm
Sensitivity ( MCS 0 ) -87 dBm @ 80 MHz
-90 dBm @ 40 MHz
-93 dBm @ 20 MHz
Antenna
Gain 14 dBi (net of losses into each of four sector panels)
Beamwidth ( 3dB ) 70º azimuth, 16º elevation
Front-to-Back Ratio >30 dB
Cross-Polar Isolation >20 dB or better
Polarization Circular, four alternating panels
Power
Max Power Consumption 25 W
System Power Method 802.3at compliant
System Lightning & ESD Protection 6 kV
PoE Power Supply 802.3at and Passive PoE compliant, 48-56 V Power over Ethernet supply with IEC61000-4-5 surge protection
Physical
Dimensions Height: 314 mm (12.36")
Width: 142 mm (5.61")
Weight 1.75 kg (3.85 lbs)
Enclosure Characteristics Outdoor UV-stabilized engineered polymer
Wind Survivability 200 km/h (125 mph)
Wind Loading 7.72 kg @ 160 km/h (17.03 lbs @ 100 mph)
Mounting Dual pole strap feed points integrated into metal base with integrated curvature for contact with mounting poles.
Environmental
Outdoor Ingress Protection Rating IP67
Operating Temperature -40°C to +55°C (-40°F to 131°F)
Operating Humidity 5 to 100% condensing
Operating Altitude 4420 m (14500') maximum
Shock & Vibration ETS 300-019-2-4 class 4M5
Features
Gigabit Ethernet 10/100/1000BASE-T
Synchronization GPS + GLONASS allows for network-wide sync and interference avoidance
Collocation 1PPS GPS Tx/Rx synchronization for same tower collocation and channel reuse
Network Processing Advanced AP control for capacity and subscriber management
Access Control Lists Permit, Deny and Remark Layer 2 and Layer 3 traffic flows
Traffic Shaping Per CPE UL/DL commit and maximum rate shaping
Management Services Mimosa cloud monitoring and management SNMPv2 & Syslog legacy monitoring HTTPS HTML5-based Web UI
2.4 GHz 802.11b/g/n radio for local management access ‡
Smart Spectrum Management Active scan monitors/logs ongoing RF interference across channels (no service impact)
Dynamic auto-optimization of channel and interference avoidance
Security WPA2 + Mimosa 802.1x RADIUS Future support of WPA2-Enterprise/HotSpot 2.0
Management VLAN support
QoS Supports 4 pre-configured QoS levels
GPS Location GNSS-1 (GPS + GLONASS)
VLANs Per subscriber VLAN; Q-in-Q, triple tagging; Management VLAN
Regulatory + Compliance
Approvals FCC Part 15.407 and Part 90Y, IC RSS210, CE,
ETSI 301 893/302 502
RoHS Compliance Yes
Safety UL/EC/EN/ 60950-1 + CSA-22.2

* 4.9 GHz uses 20 MHz channel widths (US only, regulations vary by region)

*** A5/A5c extended frequency, above 6.2 GHz, requires P/N 100-000xx-01

‡ U.S. Pat. No. US 9,179,336, US 9,295,103, US 9,161,387, US 9,130,305 and patents pending.
